10.1-inch RUGGED
TABLET PC
10.1-inch RUGGED TABLET PC
Certified ATEX for hazardous locations . Safely operates in flammable/explosive environments.
PRODUCT DESCRIPTION
10.1-inch RUGGED TABLET PC
This capacitive touch screen supports glove touch, is water mist resistant, and allows for customizable active capacitive stylus.
WIDELY APPLIED
The W105 combines durability and flexibility, making it the perfect tool for outdoor and industrial use in challenging environments.
WIDELY APPLIED
WIDELY APPLIED
The W105 combines durability and flexibility, making it the perfect tool for outdoor and industrial use in challenging environments.
EFFICIENCY AND PRECISION WITH N5105
The N5105 processor excels in energy-efficient, robust computing, ideal for industrial control, data acquisition, and automation.
EFFICIENCY AND
PRECISION WITH N5105
EFFICIENCY AND PRECISION
WITH N5105
The N5105 processor excels in energy-efficient, robust computing, ideal for industrial control, data acquisition, and automation.
WIN 10/11
10.1 inch IPS Full HD display, 10-point touch, precision and smoothness. New Win 10/11 operating system.
WIN 10/11
WIN 10/11
10.1 inch IPS Full HD display, 10-point touch, precision and smoothness. New Win 10/11 operating system.
5000MAH
>10hrs battery life, quick replacement supported.
BATTERY
REMOVABLE 5000MAH BATTERY
>10hrs battery life, quick replacement supported.
WIFI 6
Supports the latest Wi-Fi 6 technology, speed, delay, capacity is significantly improved, performance is improved again.
WIFI 6
WIFI 6
Supports the latest Wi-Fi 6 technology, speed, delay, capacity is significantly improved, performance is improved again.
GLOVE TOUCHSCREEN +
CAPACITIVE STYLUS (OPTIONAL)
Capacitive touchscreen with water resistance, supports glove operation and precise writing
10-POINT
GLOVE TOUCHSCREEN +
CAPACITIVE STYLUS (OPTIONAL)
Capacitive touchscreen with water resistance, supports glove operation and precise writing
EXTREME
TEMPERATURE ENVIRONMENT
EXTREME
TEMPERATURE
ENVIRONMENT
EXTREME TEMPERATURE
ENVIRONMENT
MULTI-INTERFACE
MULTI-INTERFACE
MULTI-INTERFACE
APPLICATION
APPLICATION
APPLICATION
APPEARANCE
TECHNICAL SPECIFICATIONS
| Hardware | |
|---|---|
| CPU | Intel® Jasper Lake N5105 |
| Graphics Card | Intel HD Graphics |
| RAM | LPDDR4 16GB on Board |
| SSD | 1*M.2 2242 Sata |
| ROM | EMMC 128GB |
| Expandable Memory | Micro SD card ( T-FLASH card), max 2TB |
| Main Camera | 5.0MP |
| Sub Camera | 2.0MP |
| Battery | 5000mAh Removable Battery |
| Display | 10.1-inch IPS FHD display 1920*1200 600 nits |
| Touch Panel | Capacitive touchscreen | Glove-touch support | Anti-fog coating | Active stylus compatible |
| IO/Sensor | |
| SIM Card/ TF Card | Nano SIM card * 1, Micro SD card * 1 (Choose any one out of two) |
| Headphone | 3.5mm Headphone Jack (four-stage US standard) |
| Charging Interface | USB Type-A (Host)*1, Type-C*1 |
| Data Interface | USB Type-A (Host)*1, Type-C*1, HDMI*1 |
| Gravity Sensor | Support |
| Charger | Input AC100~240V; Output Type-C 12V*2.5A, 30W |
| Appearance | |
| Dimensions | 262*176*18mm (L×W×H) |
| Weight (Including hand strap) | 920g |
| Material | Black & Blue (PC+ABS+TPU) |
| Communications & Networking | |
| 4G Module | Optional |
| WiFi | Dual-band WIFI (2.4GHz/5Ghz) supports WiFi 6, 802.11b/g/n/ac/ax |
| BT | 5.1 Low Energy(LE) |
| Industrial & Reliability Design | |
| Shake-proof | 1-19Hz/1.0mm; 19-200Hz/1.0g |
| Dropproof /IK | MIL-STD-810G/Method516.6/Procedure IV & Touch Panel IK05 |
| Waterproof | Class 8( IEC 60529 ) |
| Dustproof | Class 6( IEC 60529 ) |
| Reliability | MTBF>5000h; MTTR<0.5h |
| Operating Temperature | -20℃ 至 50℃ |
| Storage Temperature | -40℃ 至 80℃ |
| RH | 5% to 95% (95%RH, non-condensing) |
| Operating Altitude | Max: 4,500 m (15,000 feet) |
| Certifications & Software | |
| Certifications | 3C/FCC/CE/ROHS/IP68 (IEC 60529) |
| Language | English |
| OS | Win 10/11 |
| Package/Warranty terms | |
| Warranty | 24-month hardware warranty (12-month battery warranty) |
| Packaging box | Charger x1, USB-C data cable x1, user manual x1, screen protector (attached) x1, Packing box x1, Hand strap x1, Capacitive stylus (optional) x1 |
MODEL COMPARISON TABLE
| W105 (WIFI-X10) | W105 (WIFI-X10L) | W105 (WIFI-Ubt) | |
|---|---|---|---|
| Processor | Intel® Jasper Lake N5105 | Intel® Jasper Lake N5105 | Intel® Jasper Lake N5105 |
| Graphics Card | Intel HD Graphics | Intel HD Graphics | Intel HD Graphics |
| Memory | 16GB LPDDR4 | 8GB LPDDR4 | 16GB LPDDR4 |
| Storage | 128GB UFS | 128GB UFS | 128GB UFS |
| Charging Interface | USB Type-A(Host)*1, Type-C*1 | USB Type-A(Host)*1, Type-C*1 | USB Type-A(Host)*1, Type-C*1 |
| Data Interface | USB Type-A(Host)*1, Type-C*1, HDMI*1 | USB Type-A(Host)*1, Type-C*1, HDMI*1 | USB Type-A(Host)*1, Type-C*1, HDMI*1 |
| WiFi | Dual-band WIFI (2.4GHz/5GHz) supports WIFI 6, 802.11b/g/n/ac/ax | Dual-band WIFI (2.4GHz/5GHz) supports WIFI 6, 802.11b/g/n/ac/ax | Dual-band WIFI (2.4GHz/5GHz) supports WIFI 6, 802.11b/g/n/ac/ax |
| BT | 5.1 Low Energy (LE) | 5.1 Low Energy (LE) | 5.1 Low Energy (LE) |
| OS | Win 10/11 | Win 10/11 | Ubuntu-24.04.2-desktop |
SOURCING GUIDE
| Order No. | Model | Function Desscription |
|---|---|---|
| 05121118 | W105 (WIFI-X10) | HUGEROCK/W105-X10/16+128G/Black+Blue/1920*1200/600nits/Wifi 6/TPM/E20 |
| 05121154 | W105 (WIFI-X10L) | HUGEROCK/W105-X10L/8+128G/Black+Blue/1920*1200/600nits/Wifi 6/TPM |
| 05121170 | W105 (WIFI-Ubt) | HUGEROCK/W105-Ubt/16+128G/Black+Blue/1920*1200/600nits/Wifi 6/TPM/E20 |
SUPPORTS MODULE CUSTOMIZATION
| Barcode Module: E20 Barcode Scanner Module | |
|---|---|
| 2D | QR Code, Micro QR, Data Matrix, PDF417, Micro PDF417, Aztec, Maxicode, Hanxin Code, Dotcode, Composite. |
| 1D | Code 128 ( SBT 128, AIM 128, GSI 128 ), EAN-13, EAN-8, UPC-E, UPC-A, ISBN, ISSN, Code11,Interleaved 2 of 5, Code39, Code93, Code32, Codabar, Matrix 2 of 5, Industrial 25, IATA25, MSI Plessey, GSI DataBar, Plessey, Febraban. |
| QR Code, Micro QR, Data Matrix, PDF417, Micro PDF417, Aztec, Maxicode, Hanxin Code, Dotcode, Composite. | |
| Phone Functionality | LTE-FDD /LTE-TDD/WCDMA/GSM (Helicom EC25-EUX-M2) |
| LTE-FDD | B1//B3/B7/B8/B20/B28A |
| LTE-TDD | B38/B40/B41 |
| WCDMA | B1/B8 |
| GSM/EDGE | B3/B8 |
| GNSS | GPS/GLONASS/BeiDou (Compass)/Galileo/QZSS |
| 4G Communication Module (US) | |
| Phone Functionality | LTE-FDD /WCDMA (Helicom EC25-AFXD-M2-H) |
| LTE-FDD | B2//B4/B5/B12/B13/B14/B66/B71 |
| WCDMA | B2/B4/B5 |
| GNSS | GPS/GLONASS/BeiDou/Galileo/QZSS |
| Solid State Drive | |
| SSD | SSD-512GB、SSD-1TB、SSD-2TB (Option) |
OEM/ODM
Product Line
Research and Design
Professional Validation
Software Customization
High-Qaulity Services
Professional Certification
Modular Customization
Product Quality Testing
Product Qualification
WORRY-FREE, Focus on quality for 14 years
HARDWARE CUSTOMIZATION
- 1 ID Custom Design
- 2 MD Custom Design
- 3 PCBA Custom Development
- 4 Module Custom Developmennt
- 5 Nameplate Logo Customization
- 6 Packaging Custom Design
SOFTWARE CUSTOMIZATION
- 1 Boot Screen Customization
- 2 System Function Hiding
- 3 Built-in Customer App
- 4 Customer App Auto-launch
- 5 Platform Software Integration
- 6 Fixed MAC Address
- 7 Download Prohibition
- 8 Intercom App
- 9 USB Disablement
- 10 System Model Customization
- 11 APP Installation and Uninstallation Control
- 12 Pre-installed APK
- 13 Physical Button Disablement
- 14 Camera Control
- 15 Provide System Signing Files
FAQ
Q: Are you the manufacturer?
A: Yes, we are the manufacturer. We have our own brand HUGEROCK. All our products have complete patents - ID/MD design, hardware and software, molds, assembly are all done by our own team.
Q: Can other GIS software using serial port data work directly on your device?
A: No, we report GPS data in native ways. The serial port is already opened at the system low level. Your GIS software needs to acquire data in this way to work directly.
Q: Does it come with GIS application software?
A: Yes we have GIS software, but it requires a fee.
Q: Can you customize and pre-install our software?
A: Yes, we can pre-install your software. Customization will depend on the requirements of your software customization.
Q: Can it do differential without internet?
A: No, it requires internet to do differential.
Q: What is the minimum order quantity?
A: We accept standard product orders starting from one unit. If needed, we can even customize your logo. For OEM, our sales team will review the detailed requirements and confirm minimum order quantity.
Q: Can we get free samples?
A: Sorry, we typically do not provide free samples. If the customer confirms specifications and pricing, samples can be ordered first for testing and evaluation.
Q: How to order and pay?
A: We accept T/T (bank transfer), Alibaba online payment, Western Union.
Q: What is your product warranty?
A: We provide 24 months warranty after shipping.
Q: Can I extend the warranty period?
A: We offer extended warranty up to 36 months maximum, with a 10% price increase for extended warranty.
Q: How long is the delivery time?
A: Production lead time is approx 3–10 days, depending on requirements. Shipping time via DHL/UPS/FedEx/TNT is approx 3–5 working days. For some remote places, shipping time may be longer.
Q: How to repair if there are device issues?
A: We will provide online technical support to troubleshoot issues. For hardware issues, we can ship parts or components for customer to install (if they have technical staff) or can also ship back to us for repair.
