6.3-inch RuggedHandheld
6.3-inch RuggedHandheld
6.3-inch OLED Screen | FHD+ 1080×2340 | Slim 19.5:9 Aspect Ratio
HUGEROCK H61
Rugged Handheld
6.3-inch Rugged Industrial Multifunctional Mobile Terminal
Vendor:
SOTEN
Availability:
Out Of Stock
PRODUCT DESCRIPTION
6.3-inch Rugged Handheld
6.3-inch OLED Screen | FHD+ 1080×2340Slim 19.5:9 Aspect Ratio
WIDELY APPLIED
The H61 combines durability and flexibility,making it the perfect tool for outdoor andindustrial use in challenging environments.
WIDELY APPLIED
WIDELY APPLIED
The H61 combines durability and flexibility, making it the perfect tool for outdoor and industrial use in challenging environments.
Flagship Power
MediaTek Kompanio 900T Octa - core 2.4GHz, 6nm Process
Flagship Power
Flagship Power
MediaTek Kompanio 900T Octa - core 2.4GHz, 6nm Process
8GB+256GB Big Storage
Supports 2TB expansion
8GB+256GB
BigStorage
8GB+256GB BigStorage
CERTIFIED
Supports 2TB expansion
Android OS with GMS
Certification
Compatible with more than 20 languages
Android OS
with GMS Certification
Android OS
with GMS Certification
Compatible with more than 20 languages
Long battery life
4800mAh detachable battery with 18W PD fast charging
Long battery life
Long battery life
4800mAh detachable battery with 18W PD fast charging
5G Full Net
Supports Wi-Fi, greatly boosting speed,latency, and capacity. Performancegets a further boost to meet enterprise trends.
5G Full Net
5G Full Net
Supports Wi-Fi, greatly boosting speed, latency, and capacity. Performance gets a further boost to meet enterprise trends.
Multi-mode
Dual-band GNSS
Supports GPS/BeiDou/GLONASS/Galileo/QZSS(L1+L5 bands) AGPS + SBAS assisted positioning
Multi-mode
Dual-band GNSS
Multi-mode Dual-band GNSS
Supports GPS/BeiDou/GLONASS/Galileo/QZSS (L1+L5 bands) AGPS + SBAS assisted positioning
Rear dual-camera
Rear dual-camera
Rear dual-camera
Extreme Temperature
Environment
Stable operation at -20℃~55℃, storage temperature of -40℃~80℃
Extreme
Temperature
Environment
Extreme Temperature
Environment
Stable operation at -20℃~55℃,storage temperature of -40℃~80℃
Military protection
MIL-STD-810G military-grade certification
Military
protection
Military protection
MIL-STD-810G military-grade certification
APPlication scenario
8GB+256GB
BigStorage
8GB+256GB Big Storage
Supports 2TB expansion
APPEARANCE
SPECIFICATION
Hardware
| CPU* | MediaTek Kompanio 900T (MTK8791) Octa-core (8 cores) Up to 2.4GHz| 6nm process |
| GPU* | ARM G68 MC4 |
| AI Processing* | APU 3.0 (2.6T) |
| Memory* | 8GB LPDDR4 RAM |
| Storage* | 256GB UFS |
| Expandable Memory | Expandable via microSD (supports up to 2TB) |
| Camera* | Rear Dual Camera:Main: 48MP with autofocus & electronic flash, Secondary: 5MP wide-angle lens | Front: 8MP front-facing camera |
| Battery | 4800mAh removable battery |
| Display* | 6.3 inch OLED | 1080×2340 FHD+ resolution | 500 nits High-luminance |
| Touchscreen | Capacitive touchscreen | Glove-touch support | Anti-fog coating |
| Interfaces & Sensors | |
|---|---|
| Card Slots | Dual nano-SIM + microSD (triple slot, dual-SIM or SIM+SD) |
| Charging* | Type-C |
| Data Ports* | USB Type-C (OTG) ×1 |
| Sensors | Gravity, geomagnetic, gyroscope, rotation vector, ambient light, accelerometer |
| Charger | 5V 2A, 9V 2A, Support PD fast charge protocol |
| Navigation* | L1+L5 GPS/BeiDou/GLONASS/Galileo/QZSS with AGPS/SBAS support |
| Design & Durability | |
| Dimensions | 172 × 77 × 17mm (L×W×H) |
| Weight (including hand strap) | 300g |
| Color & Material | Black & gray PC-ABS composite |
| Connectivity | |
| Cellular* | WCDMA/LTE-TDD/LTE-FDD/5G NR |
| 2G / 3G / 4G / 5G* |
2G: GSM 850/900/1800/1900MHz 3G: WCDMA B1/B2/B5/B8 (42.2Mbps DL / 11.5Mbps UL) 4G-FDD: 150Mbps down, 50Mbps up 4G-TDD: 150Mbps downlink, 50Mbps uplink Bands: TDD-LTE (B34/38/39/40/41); FDD LTE (B1/2/3/4/5/7/8/12/17/20/26/28a&b) Cat-18 5G NR SA n1/n3/n20/n28/n41/n77/n78/n79 5G NR NSA n1/n3/n41/n77 DL 4×4 | n1/n3/n41 |
| Wireless* | Dual-band Wi-Fi 6 2×2 (2.4/5GHz, 802.11a/b/g/n/ac/ax) | BT 5.2 LE |
| Environmental Ratings | |
| Vibration | 1–19Hz/1.0mm amplitude; 19–200Hz/1.0g acceleration |
| Dropproof / IK | MIL–STD–810 compliant (1.2m) | IK05 impact protection |
| Water/Dust Resistance | IP68 (IEC 60529) |
| Operating Temperature | -20°C to 55°C |
| Storage Temperature | -40°C to 80°C |
| Reliability | MTBF ≥ 5000h; MTTR ≤ 0.5h |
| Humidity | 5% to 95% (95%RH, non-condensing) |
| Altitude | Up to 4,500m (15,000 feet) |
| Certifications & Software | |
| Certifications | 3C/FCC/CE/ROHS/IP68 (IEC 60529) |
| Language | Chinese (Simplified/Traditional), English, Spanish, Portuguese (BR/PT), Italian, German, Dutch, French, Polish, Romanian, Turkish, Russian, Arabic, Indonesian, Malay, Thai, Vietnamese, Hindi, Hebrew |
| OS* | Android 14 (GMS) Certified |
| Packaging & Warranty | |
| Warranty | 24-month device warranty (12-month battery warranty) |
| Packaging Box | Type-C cable ×1, Pre-applied screen protector ×1, Packaging box ×1, User manual ×1, Safety card ×1, Wrist strap ×1 |
MODEL COMPARISON TABLET
| Specification | H61 (5G-U62) | H61 (5G-M60) | H61 (4G-M50) |
|---|---|---|---|
| Processor | Unisoc UIS8785 Octa-core (8 cores) Up to 2.7GHz 6nm process | MediaTek Kompanio 900T (MTK8791) Octa-core (8 cores) Up to 2.4GHz 6nm process | MediaTek Helio G99 (MTK781) Octa-core (8 cores) Up to 2.2GHz 6nm process |
| Graphics | Arm MaliTM-G57 @ 850 MHz | ARM G68 MC4 | Arm MaliTM-G57 @ 850 MHz |
| AI Processing | 8 TOPS IMG AX35P96, 988 MHz | APU 3.0 (2.6 TOPS) | / |
| Memory | 8GB LPDDR4 | 8GB LPDDR4 | 8GB LPDDR4 |
| Storage | 256GB UFS | 256GB UFS | 256GB UFS |
| Charging | Type-C connector | Type-C | Type-C |
| Data Ports | USB 3.2 Gen 2 Type-C, USB & DP | USB 3.0 Type-C (OTG)*1 | Type-C (OTG)*1 |
| Navigation | Supports GPS / BeiDou / GLONASS / A-GPS / SBAS | L1+L5 dual-frequency positioning with GPS, BeiDou, GLONASS, Galileo, and QZSS support | Single-frequency, multi-constellation positioning supporting GPS, BeiDou, GLONASS, Galileo, and QZSS |
| Cellular | WCDMA/LTE-TDD/LTE-FDD/5G NR | WCDMA/LTE-TDD/LTE-FDD/5G NR | GSM/WCDMA/VoLTE |
| 3G | WCDMA B1/B5/B8 (42.2Mbps DL / 11.5Mbps UL) | WCDMA B1/B2/B5/B8 (42.2Mbps DL / 11.5Mbps UL) | WCDMA B1/B2/B5/B8 (42.2Mbps DL / 11.5Mbps UL) |
| 4G | FDD: 150Mbps down, 50Mbps UP TDD: 150Mbps downlink, 50Mbps uplink, Band: B1/3/5/8/34/38/39/40/41 Cat 12 | FDD: 150Mbps down, 50Mbps UP TDD: 150Mbps downlink, 50Mbps uplink, Band: TDD-LTE (B34/38/39/40/41); FDD LTE (B1/2/3/4/5/7/8/12/17/20/26/28a&b) | FDD: 150Mbps down, 50Mbps UP TDD: 150Mbps downlink, 50Mbps uplink, Band: TDD-LTE (B34/38/39/40/41); FDD LTE (B1/2/3/4/5/7/8/12/17/20/26/28a&b) Cat-13 DL |
| 5G | 5G NR 3GPP Release 15 NSA/SA: Sub-6 GHz SA/NSA n1/3/5/8/28/41/78/79 - DL 4×4 MIMO n1/3/41/78/79 | 5G NR SA n1/n3/n2/n20/n28/n41/n77/n78/n79 5G NR NSA n1/n3/n41/n7 DL 4x4 n1/n3/n41 | / |
| Wireless | Dual-band Wi-Fi 6 (2.4/5GHz, 802.11a/b/g/n/ac) | BT 5.0 LE | Dual-band Wi-Fi 6 (2.4/5GHz, 802.11a/b/g/n/ac/ax) | BT 5.2 LE | Dual-band Wi-Fi 6 (2.4/5GHz, 802.11a/b/g/n/ac) | BT 5.2 LE |
| OS | Harmony 4.1/Android 13 Continuous updates | Android 14 (GMS) Certified | Android 15 (GMS) Certified |
SOURCING GUIDE
| Order No. | Model | Function Description |
|---|---|---|
| 05121157 | H61 (4G-M50) | HUGEROCK/H61-M50-R/8GB+256GB/Gray+Black/1080*2340/500nits/48+5MP/E20/NFC |
| 05121156 | H61 (5G-M60) | HUGEROCK/H61-M60-R/8GB+256GB/Gray+Black/1080*2340/500nits/48+5MP/E20/NFC |
| 05121177 | H61 (5G-U62) | HUGEROCK/H61-U62-R/8GB+256GB/Gray+Black/1080*2340/500nits/48+5MP/E20/NFC |
MODULE PARAMETERS
| NFC Module | Feature Overview |
|---|---|
| Feature Overview | Integrated NFC module with standardized API interfaces, enabling mobile payment solutions and bank card transactions. |
| Operational Modes | Read/Write: Full read/write capability for NFC tag data storage and retrieval. Card Emulation: Mimics NFC cards for contactless payment systems and secure access control. Peer-to-Peer: Facilitates seamless data exchange between NFC-compatible devices. |
| Performance Metrics | Effective Range: 20-50mm tag interaction distance. Frequency: 13.56MHz high-frequency operation. |
| Supported Standards | RF Protocols: ISO/IEC 14443A/B, ISO/IEC 15693, ISO/IEC 18092, NFC Forum specifications. Tag Compatibility: Comprehensive support for industry-standard cards, including: MIFARE S50/S70, Ultralight, NTAG 203/213/215/216, FM1204/FM1208, DESFire EV1 (D21/D41/D81), SRI512/SRIX4K, iCODE, HF Tagit, and derivatives. |
| Barcode Module | Module: E20 Barcode Module |
| 2D | QR Code, Micro QR, Data Matrix, PDF417, Micro PDF417, Aztec, Maxicode, Hanxin Code, Dotcode, Composite. |
| 1D | Code 128 ( ISBT 128, AIM 128, GSI 128 ), EAN-13, EAN-8, UPC-E, UPC-A, ISBN, ISSN, Code11, Interleaved 2 of 5, Code39, Code93, Code32, Codabar, Matrix 2 of 5, Industrial 25, IATA25, MSI Plessey, GSI DataBar, Plessey, Febraban. |
OEM/ODM
Product Line
Research and Design
Professional Validation
Software Customization
High-Qaulity Services
Professional Certification
Modular Customization
Product Quality Testing
Product Qualification
WORRY-FREE, Focus on quality for 14 years
HARDWARE CUSTOMIZATION
- 1 ID Custom Design
- 2 MD Custom Design
- 3 PCBA Custom Development
- 4 Module Custom Developmennt
- 5 Nameplate Logo Customization
- 6 Packaging Custom Design
SOFTWARE CUSTOMIZATION
- 1 Boot Screen Customization
- 2 System Function Hiding
- 3 Built-in Customer App
- 4 Customer App Auto-launch
- 5 Platform Software Integration
- 6 Fixed MAC Address
- 7 Download Prohibition
- 8 Intercom App
- 9 USB Disablement
- 10 System Model Customization
- 11 APP Installation and Uninstallation Control
- 12 Pre-installed APK
- 13 Physical Button Disablement
- 14 Camera Control
- 15 Provide System Signing Files
FAQ
Q: Are you the manufacturer?
A: Yes, we are the manufacturer. We have our own brand HUGEROCK. All our products have complete patents - ID/MD design, hardware and software, molds, assembly are all done by our own team.
Q: Can other GIS software using serial port data work directly on your device?
A: No, we report GPS data in native ways. The serial port is already opened at the system low level. Your GIS software needs to acquire data in this way to work directly.
Q: Does it come with GIS application software?
A: Yes we have GIS software, but it requires a fee.
Q: Can you customize and pre-install our software?
A: Yes, we can pre-install your software. Customization will depend on the requirements of your software customization.
Q: Can it do differential without internet?
A: No, it requires internet to do differential.
Q: What is the minimum order quantity?
A: We accept standard product orders starting from one unit. If needed, we can even customize your logo. For OEM, our sales team will review the detailed requirements and confirm minimum order quantity.
Q: Can we get free samples?
A: Sorry, we typically do not provide free samples. If the customer confirms specifications and pricing, samples can be ordered first for testing and evaluation.
Q: How to order and pay?
A: We accept T/T (bank transfer), Alibaba online payment, Western Union.
Q: What is your product warranty?
A: We provide 24 months warranty after shipping.
Q: Can I extend the warranty period?
A: We offer extended warranty up to 36 months maximum, with a 10% price increase for extended warranty.
Q: How long is the delivery time?
A: Production lead time is approx 3–10 days, depending on requirements. Shipping time via DHL/UPS/FedEx/TNT is approx 3–5 working days. For some remote places, shipping time may be longer.
Q: How to repair if there are device issues?
A: We will provide online technical support to troubleshoot issues. For hardware issues, we can ship parts or components for customer to install (if they have technical staff) or can also ship back to us for repair.
