HUGEROCK R71 Sunlight Readable Droproof Android 1000nit Barcode Passenger NFC reader Ruggedized Tablet Industrial rugged Pc

Key attributes Industry-specific attributes Screen Size 7" Memory Capacity 8GB Display resolution 720*1280 Operating System Android 11...
Vendor: SOTEN
Availability: In Stock
HUGEROCK R71 Sunlight Readable Droproof Android 1000nit Barcode Passenger NFC reader Ruggedized Tablet Industrial rugged Pc

HUGEROCK R71 Sunlight Readable Droproof Android 1000nit Barcode Passenger NFC reader Ruggedized Tablet Industrial rugged Pc

$238.00 $238.00

HUGEROCK R71 Sunlight Readable Droproof Android 1000nit Barcode Passenger NFC reader Ruggedized Tablet Industrial rugged Pc

$238.00 $238.00

    PRODUCT DESCRIPTION

    img1_alt

    1000 NIT

    1000nit FHD display, combined with anti-glare reflective film technology, can clearly display in any strong light environment.

    soten
    soten
    part1_img_alt__pc

    1000 NIT

    1000 NIT

    1000nit FHD display, combined with anti-glare reflective film technology, can clearly display in any strong light environment.

    FULL RUGGED

    Industrial protection grade IP67, MIL-810G Drop-proof 1.5m.

    soten
    soten
    soten
    soten

    FULL

    RUGGED

    FULL RUGGED

    Industrial protection grade IP67, MIL-810G Drop-proof 1.5m.
    soten
    soten
    soten
    soten
    xx
    xx

    MORE FAST

    AdoptHelio P60 A73 12nm FinFET 8-core processor solution and 8G RAM.

    soten
    soten

    MORE FAST

    MORE FAST

    AdoptHelio P60 A73 12nm FinFET 8-core processor solution and 8G RAM.
    soten
    soten
    xx

    EFFICIENT

    low-power UHF RFID module and ultra-thin UHF antenna.

    soten
    soten
    soten
    xx

    EFFICIENT

    EFFICIENT

    low-power UHF RFID module and ultra-thin UHF antenna.
    soten
    soten
    soten
    img1_alt

    POWERFUL

    10000mAh battery, can work continuously for 12 hours.

    soten
    soten

    POWERFUL

    POWERFUL

    10000mAh battery, can work continuously for 12 hours.
    soten
    soten
    soten
    soten
    soten
    soten

    APPEARANCE

    xx
    xx
    xx
    xx

    SPECIFICATION

    Hardware
    CPU ARM Cortex A73 Octa-core (2.0GHz)
    GPU Arm Mali-G72 MP3
    RAM 8G
    Internal Memory 128G
    External Memory Micro SD card (T-FLASH card), max 256GB
    Main Camera 13.0MP(AF) with flash led
    Sub Camera 5.0MP
    Battery 10000mAh
    Display 7 inch IPS/AFFS 720*1280 HD industrial 1000nit Sunlight Readable
    Touch Panel Capacitive/frosted tempered film supports glove touch/spray/active capacitive pen
    IO/Sensor/Navigation
    SIM Card 1.8/3.3V SIM card
    TF Card Micro SD card (T-FLASH card); max 256GB
    Headphone 3.5mm (CTIA)
    Charging interface Type-C+ 8PIN magnetic charging
    Data interface USB Type-A(Host)*1, Type-C*1
    Gravity sensor support
    Direction Sensor support
    Magnetic Field Sensor support
    Gyro sensor support
    Rotation Vector support
    Light-sensor support
    Acceleration sensor support
    Motion sensor support
    Charger 5.0V 2A-10W
    Navigation GPS+Beidou+Glonass+AGPS+SBAS (EPO 2.5m)
    Appearance
    Size 202*138*22mm (LxWxH)
    Weight 700g
    Color & Material Black&Gray
    Communications & Networking
    Phone Call GSM /WCDMA/CDMA 1X/VoLTE
    2G GSM/CDMA 1X/EDGE/GPRS/WAP
    2G Band GSM (B2/3/5/8)
    3G WCDMA
    3G Band WCDMA 3.75G (HSDPA + 42.2Mbps, HSUPA + 11.5Mbps), EVDO
    4G FDD: 150Mbps down, 50Mbps UP TDD: 150Mbps downlink, 50Mbps uplink
    4G Band TD-LTE (B38/39/40/41); FDD LTE (B1/2/3/4/5/7/8/12/17/20/28)
    WI- FI Dual-band WIFI (2.4GHz/5Ghz) single stream 802.11 a/b/g/n/ac
    Bluetooth 4.2 Low Energy (LE)
    Industrial & Reliability Design
    Shake-proof 1-19Hz/ 0.10mm; 19-200Hz/1.0g
    Dropproof /IK MIL-STD-810G/Method516.6/Procedure IV & Touch Panel IK05
    Waterproof Class 7 (IEC 60529)
    Dustproof Class 6 (IEC 60529)
    Operating temperature -20℃ to 55℃
    Storage Temperature -40℃ to 80℃
    Reliability MTBF=50000h; MTTR=0.5h
    RH 5%RH-95%
    Operating Altitude Max: 4,500m (15,000 feet)
    Certification/OS/Software
    Certification 3C/FCC/CE/ROHS/IP67 (IEC 60529)
    Language English, Spanish, Portuguese (Brazil), Portuguese (Portugal), Italian, German, Dutch, French, Polish, Romanian, Turkish, Russian, Arabic, Indonesian, Malay, Thai, Vietnamese, Hindi, Hebrew, Simplified, Chinese, Chinese Traditional, etc.
    OS Android 10 / 11
    Package/Warranty terms/OEM
    Warranty 24 months
    OEM/ODM Support
    Package USB cable/Charger 5V 2A/Introduction manual/Screen protector/Packing box (Can be customized logo)

    FUNCTION MODULES

    LF RFlD data module
    125K LF 125K LF RFID LF RFID,125K
    134K LF 134 LF RFID Module LF RFID, 134k Animal module
    HF RFID/NFC module
    HF&LF dualfrequency ID/lCcard read-only module
    Frequency 13.56MHz
    Protocol standard IS014443A/B,IS015693,NFC
    13.56M HF multi-protocol module
    Label standard M1(S50, S70), CPU, NFC
    NFC module
    Read-write distance 2-5cm
    UHF module
    UHF module (M500+Ceramic antenna) Air interface protocol EPCglobal UHF Class 1 Gen2/1s0 18000-6C
    Operating spectrum range 902Mhz – 928Mhz 865MHz – 868MHz(Optional)
    Output range 0-26bdm
    Output accuracy +/- 1dB
    Output power level +/-0.2dB ,The label is sensitive and stable
    Reading distance ≥1.8m(E41 tag)

    LF RFlD data module
    125K LF 125K LF RFID LF RFID,125K
    134K LF 134 LF RFID Module LF RFID, 134k Animal module
    HF RFID/NFC module
    HF&LF dualfrequency ID/lCcard read-only module
    Frequency 13.56MHz
    Protocol standard IS014443A/B,IS015693,NFC
    13.56M HF multi-protocol module
    Label standard M1(S50, S70), CPU, NFC
    NFC module
    Read-write distance 2-5cm
    UHF module
    UHF module (M500+Ceramic antenna) Air interface protocol EPCglobal UHF Class 1 Gen2/1s0 18000-6C
    Operating spectrum range 902Mhz – 928Mhz 865MHz – 868MHz(Optional)
    Output range 0-26bdm
    Output accuracy +/- 1dB
    Output power level +/-0.2dB ,The label is sensitive and stable
    Reading distance ≥1.8m(E41 tag)

    OEM/ODM

    Product Line
    Research and Design
    Professional Validation
    Software Customization
    High-Qaulity Services
    Professional Certification
    Modular Customization
    Product Quality Testing

    Product Qualification

    WORRY-FREE, Focus on quality for 14 years

    Life cycle is greater than 5 years
    Two-Year Warranty For Device
    Unpacking Failure, Free Replacement Whitin 30 Days
    More Than 100 Units, 1% Space Parts Gurantee
    HARDWARE CUSTOMIZATION
    • 1 ID Custom Design
    • 2 MD Custom Design
    • 3 PCBA Custom Development
    • 4 Module Custom Developmennt
    • 5 Nameplate Logo Customization
    • 6 Packaging Custom Design
    SOFTWARE CUSTOMIZATION
    • 1 Boot Screen Customization
    • 2 System Function Hiding
    • 3 Built-in Customer App
    • 4 Customer App Auto-launch
    • 5 Platform Software Integration
    • 6 Fixed MAC Address
    • 7 Download Prohibition
    • 8 Intercom App
    • 9 USB Disablement
    • 10 System Model Customization
    • 11 APP Installation and Uninstallation Control
    • 12 Pre-installed APK
    • 13 Physical Button Disablement
    • 14 Camera Control
    • 15 Provide System Signing Files

    FAQ

    Q: Are you the manufacturer?

    A: Yes, we are the manufacturer. We have our own brand HUGEROCK. All our products have complete patents - ID/MD design, hardware and software, molds, assembly are all done by our own team.

    Q: Can other GIS software using serial port data work directly on your device?

    A: No, we report GPS data in native ways. The serial port is already opened at the system low level. Your GIS software needs to acquire data in this way to work directly.

    Q: Does it come with GIS application software?

    A: Yes we have GIS software, but it requires a fee.

    Q: Can you customize and pre-install our software?

    A: Yes, we can pre-install your software. Customization will depend on the requirements of your software customization.

    Q: Can it do differential without internet?

    A: No, it requires internet to do differential.

    Q: What is the minimum order quantity?

    A: We accept standard product orders starting from one unit. If needed, we can even customize your logo. For OEM, our sales team will review the detailed requirements and confirm minimum order quantity.

    Q: Can we get free samples?

    A: Sorry, we typically do not provide free samples. If the customer confirms specifications and pricing, samples can be ordered first for testing and evaluation.

    Q: How to order and pay?

    A: We accept T/T (bank transfer), Alibaba online payment, Western Union.

    Q: What is your product warranty?

    A: We provide 24 months warranty after shipping.

    Q: Can I extend the warranty period?

    A: We offer extended warranty up to 36 months maximum, with a 10% price increase for extended warranty.

    Q: How long is the delivery time?

    A: Production lead time is approx 3–10 days, depending on requirements. Shipping time via DHL/UPS/FedEx/TNT is approx 3–5 working days. For some remote places, shipping time may be longer.

    Q: How to repair if there are device issues?

    A: We will provide online technical support to troubleshoot issues. For hardware issues, we can ship parts or components for customer to install (if they have technical staff) or can also ship back to us for repair.
